Why the granite segments is always dropped?

During the cutting process of granite, the saw blade rotates rapidly and continuously moves back and forth (also called knife) and cuts downward (also called lower knife). The segment of the saw blade and the stone are constantly colliding, rubbing, and colliding. If the force is too large, or the friction resistance exceeds the welding strength of the saw blade segment, then the segment will lose teeth. Or the quality of the segment is not good, the segment has been cracked during the cutting process, or the non-working layer and the working layer have cracks. During the cutting process, the cracks increase and the teeth are lost. It can be seen that the most important reason for saw blade tooth loss is the quality of the segment and welding problems. Then, based on these two aspects, we conduct a more in-depth study.

The segment falling off caused by the quality of the segment may mainly have the following reasons:

1: The formula of the segment does not match: the segment must be adjusted according to the softness and hardness of the cutting granite during the process of mixing. During the cutting process, if the stone is too hard, the hardness of the diamond powder in the segment is not enough. The segment will withstand greater impulse during the cutting process. When the impulse reaches the critical point, the segemnt will fall off. This situation is more severe, and the segment will drop in a wide range.



2: Uneven mixing of the segment: In the initial mixing process, the mixing time of the segment is too short, resulting in uneven mixing. In the later sintering process, product instability has formed, so the quality of the segment will also appear instability leads to falling, but this situation is relatively rare (generally, the segment produced by large manufacturers has the weight test of the final product to avoid this type of problem, while the small plant does not have this test). Part of the segment will drop.

3: The sintering temperature of the segment is not enough or the pressure is not enough: Insufficient temperature of the segment will lead to insufficient sintering of the segment binder, resulting in a significant reduction in the chemical stress and material stress of the segment, and the cutting process will not move. In addition, the material structure of the segment is not strong, resulting in tooth loss.

4: The sintering temperature or pressure is too high: excessive sintering of diamond agglomerates will lead to excessive carbonization of the diamond, thereby weakening the cutting ability, and the metal bond will also form a denser structure due to excessive high pressure, which is not easy to consume, resulting in a tool tip After the diamond is worn out and the carcass is not worn, after the segment becomes blunt, if the cutting speed and plunge speed are still maintained to cut granite, the impact and friction will increase, causing the segment to fall off.

In addition to the problems of the segment itself, welding is also the cause of the segment falling off, mainly as follows:

1: The solder selection is wrong. Choose different solders according to different uses and different hardness of granite. If the wrong solder is used, it will lead to insufficient soldering firmness and result in tooth loss.



2: Welding operation: When welding, the temperature should be raised rapidly, and the welding should be done quickly and fully to shorten the welding time and ensure the welding firmness. Therefore, welding has also become an advanced technical job, and it is difficult for non-professional personnel to grasp its difficulties.

3: Inspection: The inspection after welding is particularly important, especially the use of a firmness inspection tool to test each segment.

The drop of the diamond segment is mostly due to human factors. If the segment does not lose its teeth, it is especially important to choose a responsible diamond segment manufacturer, such as Linxing Diamond Tools. For many years, the company has been relying on quality for survival and product quality. The idea is to let the company do careful inspection of each segment, so that customers can weld with confidence.
