The diamond wire saw swivel pulley, also known as the horizontal swivel pulley, is a rotating wheel assembly located at the front of the wire saw. Its primary function is to support and guide the movement of the wire saw during cutting. The swivel pulley consists of multiple rotating wheels that can freely rotate in different directions, providing flexibility and stability to the wire saw during the cutting process.
The design of the horizontal swivel pulley allows the wire saw to adapt to various angles and curved shapes, offering enhanced cutting capabilities. It can easily handle complex cutting tasks, such as curves, arcs, and irregular shapes. By rotating and turning, the horizontal swivel pulley enables the wire saw to cut in different directions and angles, ensuring precise and smooth cutting lines.
Made from wear-resistant materials such as metal or durable plastics, the swivel pulleys possess high abrasion resistance and impact resistance, capable of withstanding vibrations and pressures during cutting. In essence, the horizontal swivel pulley plays a critical role in providing stability and flexibility to the wire saw, enabling it to meet diverse cutting requirements. It is an essential cutting tool for diamond wire saws.
Regarding the working principle of the horizontal swivel pulley, it functions as follows:
Supporting and guiding the wire saw: Positioned at the front of the wire saw, the horizontal swivel pulley's wheels typically comprise metal or other wear-resistant materials. As the wire saw moves during cutting, the pulley's wheels make contact with the cutting surface, providing support and guiding the wire saw.
Turning and rotating: The wheels of the horizontal swivel pulley can freely rotate and possess turning capabilities. They can rotate horizontally to adapt to different angles and curved shapes during cutting. By rotating and turning, the horizontal swivel pulley allows the wire saw to cut in various directions and angles, ensuring cutting accuracy and smoothness.
Stable cutting: The working of the horizontal swivel pulley helps the wire saw maintain stability during cutting. It offers additional support and guidance, reducing the wire saw's jitter and wobbling during the cutting process. This contributes to more accurate and smooth cutting, enhancing cutting quality and efficiency.
In summary, the horizontal swivel pulley enhances the control and stability of the diamond wire saw through support, guidance, turning, and rotation. It allows the wire saw to move flexibly during cutting, accommodating different angles and curved shapes, ensuring precise and smooth cutting.
